This lot contains 16 pcs of the keyfoundation elements of the Lockheed L-2000 SST development, testing and manufacturing behind it andeach is integral as a priceless collection of Phase II and Phase III
Pc 1– Lockheed Volume #19848of Phase III Volume IV-C System integration Product Assurance, 1966 This is thelargest source I have ever found with a Very thorough detail of thedevelopment, testing and management for L-2000 Phase III – includes multiplefoldouts and images in great condition, its cover had deteriorated and ismissing. – 200 pages
Pc 2 – Lockheed Volume #18185of Phase II-A Summary This is a professional done bound copy of the originalfrom 1964 that I no longer own, completed with tabs – Complete with foldouts,images and illustrations – 120 pages
Pc 3 – North American NA-66-395Technical Proposal for the Fabrication of Lockheed’s SST Structure by DiffusionBonding April 1966 – includes fold outs, 24 pages.
Pc 4 – Lockheed Volume – “ValueControl at Lockheed California” basic sales pitch volume used to promoteLockheed’s aggressive style of management. – roughly 100+ pages
Pc 5 – “SST Material” Folderfrom named and un named Lockheed Engineers and managers with detailed notes andinterdepartmental company details from reviews, status reports, to Heattreatment of TI and more, uncounted but probably 100-150 pages.
Pc 6 – B&W Photograph of the Phase III mock up, I think this a fake made tolook original, as I recall on close inspection but still cool. B&W 7” x10”
Pc 7 – Douglas Missile &Space Systems Division – Production Diffusion Bonding of Titanium StructureBrochure – 1965 – 24 pages
Pc 8 – Sciaky - Electron BeamWelding Sales Brochure – 4 pages
Pc 9 – Lockheed – Value Control– Management and cost control sales brochure – 1962 – 4 pages
Pc 10 – Lockheed – ValueEngineering – Management sales brochure – 1962 – 8 pages
Pc 11 – Lockheed – 42” X 100+”Blueprint – SST Wing Skin Panel - July 1966
Pc 12 – Lockheed - 36.5” X88” Blueprint – SST Main Wing Edge Attachement – September 1966
Pc 13 – Lockheed – 36.5” X 89”Blueprint – SST Main Wing Edge Attachement – September 1966 original Copy 2 of above pc 12
Pc 14 – Lockheed – 34” X 84” Blueprint – SST Fuselage Ring, Stringer, Skin StudyDesign Trade Off – 1965
Pc 15 – Lockheed – 24” X 36”Blueprint – SST Master Breakdown – February 1966
Pc 16 – Lockheed – 24” X 36”Blueprint – SST Wing Box - 1966
